#include <Arduino.h>
#include <WiFi.h>

#include "ConfigStore.h"
#include "DataAggregator.h"
#include "module/NetworkUploader.h"
#include "sensor/AudioSampler.h"
#include "sensor/I2cSensorManager.h"
#include "sensor/Types.h"

namespace {
QueueHandle_t sensorQueue;
QueueHandle_t uploadQueue;
SemaphoreHandle_t dataMutex;
SemaphoreHandle_t configMutex;

LatestData latestData;
ConfigStore configStore;
I2cSensorManager i2cSensors;
AudioSampler audioSampler;
DataAggregator dataAggregator;
NetworkUploader networkUploader;

String wifiHostname;

String normalizedHostnameFromDeviceId(const char *deviceId) {
  String hostname = "fenghou-";
  hostname += deviceId;
  hostname.toLowerCase();

  for (size_t i = 0; i < hostname.length(); i++) {
    char c = hostname.charAt(i);
    bool allowed = (c >= 'a' && c <= 'z') || (c >= '0' && c <= '9') || c == '-';
    if (!allowed) {
      hostname.setCharAt(i, '-');
    }
  }

  return hostname;
}

void onWiFiEvent(WiFiEvent_t event, WiFiEventInfo_t info) {
  switch (event) {
  case ARDUINO_EVENT_WIFI_STA_START:
    Serial.println("[wifi-event] STA start");
    break;
  case ARDUINO_EVENT_WIFI_STA_CONNECTED:
    Serial.println("[wifi-event] STA connected to AP");
    break;
  case ARDUINO_EVENT_WIFI_STA_GOT_IP:
    Serial.print("[wifi-event] got IP: ");
    Serial.println(WiFi.localIP());
    break;
  case ARDUINO_EVENT_WIFI_STA_DISCONNECTED:
    Serial.print("[wifi-event] STA disconnected, reason=");
    Serial.println(info.wifi_sta_disconnected.reason);
    break;
  default:
    break;
  }
}

void taskI2CSensors(void *) {
  i2cSensors.run();
}

void taskAudio(void *) {
  audioSampler.run();
}

void taskDataProcess(void *) {
  dataAggregator.run();
}

void taskNetworkUpload(void *) {
  networkUploader.run();
}
} // namespace

void setup() {
  Serial.begin(115200);
  unsigned long serialWaitStart = millis();
  while (!Serial && millis() - serialWaitStart < 3000) {
    delay(10);
  }
  delay(2000);

  sensorQueue = xQueueCreate(12, sizeof(SensorSample));
  uploadQueue = xQueueCreate(3, sizeof(LatestData));
  dataMutex = xSemaphoreCreateMutex();
  configMutex = xSemaphoreCreateMutex();
  if (!sensorQueue || !uploadQueue || !dataMutex || !configMutex) {
    Serial.println("FreeRTOS allocation failed.");
    while (true) {
      delay(1000);
    }
  }

  if (!configStore.begin(configMutex)) {
    Serial.println("Preferences init failed.");
  }
  configStore.load();

  DeviceConfig cfg;
  configStore.getCopy(&cfg);
  wifiHostname = normalizedHostnameFromDeviceId(cfg.deviceId);
  WiFi.onEvent(onWiFiEvent);
  WiFi.mode(WIFI_STA);
  WiFi.setSleep(false);
  WiFi.setHostname(wifiHostname.c_str());
  WiFi.persistent(false);

  Serial.println("Fenghou on-device monitor booting");
  Serial.printf("Config: valid=%d ssid=%s server=%s device=%s\n",
                cfg.valid,
                cfg.ssid,
                cfg.server,
                cfg.deviceId);
  Serial.print("WiFi hostname: ");
  Serial.println(wifiHostname);

  i2cSensors.begin(sensorQueue, &configStore, dataMutex, &latestData);
  audioSampler.begin(sensorQueue);
  dataAggregator.begin(sensorQueue, uploadQueue, dataMutex, &latestData, &configStore);
  networkUploader.begin(uploadQueue, &configStore);

  xTaskCreate(taskI2CSensors, "i2c", 6144, nullptr, 2, nullptr);
  xTaskCreate(taskAudio, "audio", 4096, nullptr, 3, nullptr);
  xTaskCreate(taskDataProcess, "data", 4096, nullptr, 1, nullptr);
  xTaskCreate(taskNetworkUpload, "upload", 6144, nullptr, 2, nullptr);
}

void loop() {
  vTaskDelay(pdMS_TO_TICKS(1000));
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608

#include "I2cSensorManager.h"

#include <Wire.h>
#include <math.h>

#include "../DebugLog.h"

void I2cSensorManager::begin(QueueHandle_t sampleQueue,
                             ConfigStore *configStore,
                             SemaphoreHandle_t dataMutex,
                             LatestData *latestData) {
  sampleQueue_ = sampleQueue;
  configStore_ = configStore;
  dataMutex_ = dataMutex;
  latestData_ = latestData;
}

void I2cSensorManager::run() {
  Wire.begin(PIN_I2C_SDA, PIN_I2C_SCL);
  Wire.setClock(I2C_CLOCK_HZ);
  Wire.setTimeOut(50);
  vTaskDelay(pdMS_TO_TICKS(100));

  scanI2cBus();

  aht20Present_ = i2cDevicePresent(AHT20_ADDR);
  bmp280Present_ = bmp280Begin();
  sgp30Present_ = i2cDevicePresent(SGP30_ADDR) && sgp30Begin();
  as7341Present_ = as7341Setup();
  st25Present_ = i2cDevicePresent(ST25_USER_ADDR);
  DEBUG_LOG("[sensor:init] sda=%d scl=%d aht20=%d bmp280=%d sgp30=%d as7341=%d st25=%d\n",
            PIN_I2C_SDA,
            PIN_I2C_SCL,
            aht20Present_ ? 1 : 0,
            bmp280Present_ ? 1 : 0,
            sgp30Present_ ? 1 : 0,
            as7341Present_ ? 1 : 0,
            st25Present_ ? 1 : 0);

  uint32_t lastAht = 0;
  uint32_t lastBmp = 0;
  uint32_t lastSgp = 0;
  uint32_t lastAs = 0;
  uint32_t lastNfc = 0;

  for (;;) {
    uint32_t now = millis();

    if (now - lastNfc >= 5000) {
      lastNfc = now;
      pollNfc(now);
    }
    if (now - lastAht >= 2000) {
      lastAht = now;
      pollAht(now);
    }
    if (now - lastBmp >= 5000) {
      lastBmp = now;
      pollBmp(now);
    }
    if (now - lastSgp >= 1000) {
      lastSgp = now;
      pollSgp(now);
    }
    if (now - lastAs >= 5000) {
      lastAs = now;
      pollAs7341(now);
    }

    vTaskDelay(pdMS_TO_TICKS(50));
  }
}

void I2cSensorManager::sendSample(const SensorSample &sample) {
  xQueueSend(sampleQueue_, &sample, QUEUE_WAIT);
}

void I2cSensorManager::pollNfc(uint32_t now) {
  if (!st25Present_) {
    return;
  }
  char raw[256];
  if (!st25ReadUserMemory(raw, sizeof(raw))) {
    return;
  }
  DEBUG_LOG("[sensor:nfc] raw=%s\n", raw);
  if (!configStore_ || !configStore_->applyPayload(raw)) {
    return;
  }

  SensorSample sample = {};
  sample.kind = KIND_CONFIG;
  sample.ms = now;
  sample.ok = true;
  sendSample(sample);
  Serial.println("NFC config updated.");
}

void I2cSensorManager::pollAht(uint32_t now) {
  SensorSample sample = {};
  sample.kind = KIND_AHT;
  sample.ms = now;
  sample.ok = aht20Present_ && aht20Read(&sample.temperatureC, &sample.humidityRh);
  DEBUG_LOG("[sensor:aht20] ok=%d temperature_c=%.2f humidity_rh=%.2f\n",
            sample.ok ? 1 : 0,
            sample.temperatureC,
            sample.humidityRh);
  sendSample(sample);
}

void I2cSensorManager::pollBmp(uint32_t now) {
  SensorSample sample = {};
  sample.kind = KIND_BMP;
  sample.ms = now;
  sample.ok = bmp280Read(&sample.temperatureC, &sample.pressureHpa, &sample.altitudeM);
  DEBUG_LOG("[sensor:bmp280] ok=%d temperature_c=%.2f pressure_hpa=%.2f altitude_m=%.1f\n",
            sample.ok ? 1 : 0,
            sample.temperatureC,
            sample.pressureHpa,
            sample.altitudeM);
  sendSample(sample);
}

void I2cSensorManager::pollSgp(uint32_t now) {
  SensorSample sample = {};
  sample.kind = KIND_AIR;
  sample.ms = now;
  sample.sgpWarmup = sgp30StartMs_ == 0 || now - sgp30StartMs_ < 15000;

  LatestData copy;
  xSemaphoreTake(dataMutex_, portMAX_DELAY);
  copy = *latestData_;
  xSemaphoreGive(dataMutex_);

  if (sgp30Present_) {
    uint32_t ah = absoluteHumidityMgM3(copy.temperatureC, copy.humidityRh);
    if (ah) {
      sgp30SetHumidity(ah);
    }
    sample.ok = sgp30Read(&sample.eco2Ppm, &sample.tvocPpb);
  }
  DEBUG_LOG("[sensor:sgp30] present=%d ok=%d eco2_ppm=%u tvoc_ppb=%u warmup=%d\n",
            sgp30Present_ ? 1 : 0,
            sample.ok ? 1 : 0,
            sample.eco2Ppm,
            sample.tvocPpb,
            sample.sgpWarmup ? 1 : 0);
  sendSample(sample);
}

void I2cSensorManager::pollAs7341(uint32_t now) {
  SensorSample sample = {};
  sample.kind = KIND_LIGHT;
  sample.ms = now;
  sample.ok = as7341Present_ && as7341Read(sample.f, &sample.clear, &sample.nir);
  if (!sample.ok && i2cDevicePresent(AS7341_ADDR)) {
    as7341Present_ = as7341Setup();
  }
  DEBUG_LOG("[sensor:as7341] ok=%d f=[%u,%u,%u,%u,%u,%u,%u,%u] clear=%u nir=%u\n",
            sample.ok ? 1 : 0,
            sample.f[0], sample.f[1], sample.f[2], sample.f[3],
            sample.f[4], sample.f[5], sample.f[6], sample.f[7],
            sample.clear,
            sample.nir);
  sendSample(sample);
}

void I2cSensorManager::scanI2cBus() {
  DEBUG_LOG("[i2c:scan] start sda=%d scl=%d clock=%lu\n",
            PIN_I2C_SDA,
            PIN_I2C_SCL,
            static_cast<unsigned long>(I2C_CLOCK_HZ));

  uint8_t found = 0;
  for (uint8_t addr = 1; addr < 0x7F; addr++) {
    Wire.beginTransmission(addr);
    uint8_t err = Wire.endTransmission();
    if (err == 0) {
      found++;
      DEBUG_LOG("[i2c:scan] found addr=0x%02X%s%s%s%s%s\n",
                addr,
                addr == AHT20_ADDR ? " AHT20" : "",
                addr == AS7341_ADDR ? " AS7341" : "",
                addr == SGP30_ADDR ? " SGP30" : "",
                (addr == BMP280_ADDR_PRIMARY || addr == BMP280_ADDR_SECONDARY) ? " BMP280" : "",
                addr == ST25_USER_ADDR ? " ST25" : "");
    } else if (err == 4) {
      DEBUG_LOG("[i2c:scan] unknown error addr=0x%02X err=%u\n", addr, err);
    }
    vTaskDelay(pdMS_TO_TICKS(1));
  }

  DEBUG_LOG("[i2c:scan] done found=%u\n", found);
}

bool I2cSensorManager::i2cWrite(uint8_t addr, const uint8_t *data, size_t len) {
  Wire.beginTransmission(addr);
  Wire.write(data, len);
  uint8_t err = Wire.endTransmission();
  if (err != 0) {
    DEBUG_LOG("[i2c:write-fail] addr=0x%02X len=%u err=%u\n",
              addr,
              static_cast<unsigned int>(len),
              err);
    return false;
  }
  return true;
}

bool I2cSensorManager::i2cWriteByte(uint8_t addr, uint8_t reg, uint8_t value) {
  uint8_t data[2] = {reg, value};
  return i2cWrite(addr, data, sizeof(data));
}

bool I2cSensorManager::i2cReadReg(uint8_t addr, uint8_t reg, uint8_t *buf, size_t len) {
  Wire.beginTransmission(addr);
  Wire.write(reg);
  uint8_t err = Wire.endTransmission(false);
  if (err != 0) {
    DEBUG_LOG("[i2c:read-reg-fail] phase=write-addr addr=0x%02X reg=0x%02X len=%u err=%u\n",
              addr,
              reg,
              static_cast<unsigned int>(len),
              err);
    return false;
  }
  size_t got = Wire.requestFrom(addr, static_cast<uint8_t>(len));
  if (got != len) {
    DEBUG_LOG("[i2c:read-reg-fail] phase=request addr=0x%02X reg=0x%02X len=%u got=%u\n",
              addr,
              reg,
              static_cast<unsigned int>(len),
              static_cast<unsigned int>(got));
    return false;
  }
  for (size_t i = 0; i < len; i++) {
    buf[i] = Wire.read();
  }
  return true;
}

bool I2cSensorManager::i2cDevicePresent(uint8_t addr) {
  Wire.beginTransmission(addr);
  uint8_t err = Wire.endTransmission();
  DEBUG_LOG("[i2c:probe] addr=0x%02X present=%d err=%u\n",
            addr,
            err == 0 ? 1 : 0,
            err);
  return err == 0;
}

uint16_t I2cSensorManager::le16(const uint8_t *p) {
  return static_cast<uint16_t>(p[0]) | (static_cast<uint16_t>(p[1]) << 8);
}

int16_t I2cSensorManager::sle16(const uint8_t *p) {
  return static_cast<int16_t>(le16(p));
}

uint8_t I2cSensorManager::crc8Sgp30(const uint8_t *data, uint8_t len) {
  uint8_t crc = 0xFF;
  for (uint8_t i = 0; i < len; i++) {
    crc ^= data[i];
    for (uint8_t bit = 0; bit < 8; bit++) {
      crc = (crc & 0x80) ? (crc << 1) ^ 0x31 : (crc << 1);
    }
  }
  return crc;
}

bool I2cSensorManager::sgp30Command(const uint8_t *cmd,
                                    uint8_t cmdLen,
                                    uint16_t delayMs,
                                    uint16_t *words,
                                    uint8_t wordCount) {
  if (!i2cWrite(SGP30_ADDR, cmd, cmdLen)) {
    return false;
  }
  vTaskDelay(pdMS_TO_TICKS(delayMs));
  if (wordCount == 0) {
    return true;
  }

  const uint8_t replyLen = wordCount * 3;
  uint8_t reply[18];
  if (replyLen > sizeof(reply)) {
    return false;
  }
  size_t got = Wire.requestFrom(SGP30_ADDR, replyLen);
  if (got != replyLen) {
    DEBUG_LOG("[i2c:request-fail] sensor=sgp30 addr=0x%02X len=%u got=%u\n",
              SGP30_ADDR,
              replyLen,
              static_cast<unsigned int>(got));
    return false;
  }
  for (uint8_t i = 0; i < replyLen; i++) {
    reply[i] = Wire.read();
  }
  for (uint8_t i = 0; i < wordCount; i++) {
    uint8_t *p = &reply[i * 3];
    if (crc8Sgp30(p, 2) != p[2]) {
      return false;
    }
    words[i] = (static_cast<uint16_t>(p[0]) << 8) | p[1];
  }
  return true;
}

bool I2cSensorManager::sgp30Begin() {
  uint8_t iaqInit[] = {0x20, 0x03};
  if (!sgp30Command(iaqInit, sizeof(iaqInit), 10)) {
    return false;
  }
  sgp30StartMs_ = millis();
  return true;
}

uint32_t I2cSensorManager::absoluteHumidityMgM3(float temperatureC, float humidityRh) {
  if (!isfinite(temperatureC) || !isfinite(humidityRh)) {
    return 0;
  }
  const float ah = 216.7f *
                   ((humidityRh / 100.0f) * 6.112f *
                    expf((17.62f * temperatureC) / (243.12f + temperatureC)) /
                    (273.15f + temperatureC));
  if (ah <= 0.0f) {
    return 0;
  }
  return static_cast<uint32_t>(ah * 1000.0f);
}

bool I2cSensorManager::sgp30SetHumidity(uint32_t absoluteHumidity) {
  if (absoluteHumidity > 256000) {
    return false;
  }
  uint16_t scaled = static_cast<uint16_t>(((uint64_t)absoluteHumidity * 256 * 16777) >> 24);
  uint8_t cmd[5] = {0x20, 0x61, static_cast<uint8_t>(scaled >> 8), static_cast<uint8_t>(scaled & 0xFF), 0};
  cmd[4] = crc8Sgp30(cmd + 2, 2);
  return sgp30Command(cmd, sizeof(cmd), 10);
}

bool I2cSensorManager::sgp30Read(uint16_t *eco2, uint16_t *tvoc) {
  uint8_t cmd[] = {0x20, 0x08};
  uint16_t words[2];
  if (!sgp30Command(cmd, sizeof(cmd), 12, words, 2)) {
    return false;
  }
  *eco2 = words[0];
  *tvoc = words[1];
  DEBUG_LOG("[sensor:sgp30:raw] words=%u,%u\n", words[0], words[1]);
  return true;
}

bool I2cSensorManager::aht20Read(float *temperatureC, float *humidityRh) {
  uint8_t status = 0;
  if (!i2cReadReg(AHT20_ADDR, 0x71, &status, 1)) {
    return false;
  }
  if ((status & 0x18) != 0x18) {
    uint8_t initCmd[] = {0xBE, 0x08, 0x00};
    i2cWrite(AHT20_ADDR, initCmd, sizeof(initCmd));
    vTaskDelay(pdMS_TO_TICKS(10));
  }

  uint8_t trig[] = {0xAC, 0x33, 0x00};
  if (!i2cWrite(AHT20_ADDR, trig, sizeof(trig))) {
    return false;
  }
  vTaskDelay(pdMS_TO_TICKS(80));

  uint8_t data[7];
  size_t got = Wire.requestFrom(AHT20_ADDR, static_cast<uint8_t>(7));
  if (got != 7) {
    DEBUG_LOG("[i2c:request-fail] sensor=aht20 addr=0x%02X len=7 got=%u\n",
              AHT20_ADDR,
              static_cast<unsigned int>(got));
    return false;
  }
  for (uint8_t i = 0; i < 7; i++) {
    data[i] = Wire.read();
  }
  if (data[0] & 0x80) {
    return false;
  }

  uint32_t rawHumidity = ((uint32_t)data[1] << 12) | ((uint32_t)data[2] << 4) | (data[3] >> 4);
  uint32_t rawTemperature = ((uint32_t)(data[3] & 0x0F) << 16) | ((uint32_t)data[4] << 8) | data[5];
  DEBUG_LOG("[sensor:aht20:raw] status=0x%02X bytes=%02X %02X %02X %02X %02X %02X %02X raw_h=%lu raw_t=%lu\n",
            data[0], data[0], data[1], data[2], data[3], data[4], data[5], data[6],
            static_cast<unsigned long>(rawHumidity),
            static_cast<unsigned long>(rawTemperature));
  *humidityRh = rawHumidity * 100.0f / 1048576.0f;
  *temperatureC = rawTemperature * 200.0f / 1048576.0f - 50.0f;
  return true;
}

bool I2cSensorManager::bmp280ReadCoefficients(uint8_t addr) {
  uint8_t c[24];
  if (!i2cReadReg(addr, 0x88, c, sizeof(c))) {
    return false;
  }
  bmpDigT1_ = le16(c + 0);
  bmpDigT2_ = sle16(c + 2);
  bmpDigT3_ = sle16(c + 4);
  bmpDigP1_ = le16(c + 6);
  bmpDigP2_ = sle16(c + 8);
  bmpDigP3_ = sle16(c + 10);
  bmpDigP4_ = sle16(c + 12);
  bmpDigP5_ = sle16(c + 14);
  bmpDigP6_ = sle16(c + 16);
  bmpDigP7_ = sle16(c + 18);
  bmpDigP8_ = sle16(c + 20);
  bmpDigP9_ = sle16(c + 22);
  return bmpDigP1_ != 0;
}

bool I2cSensorManager::bmp280Begin() {
  uint8_t id = 0;
  if (i2cReadReg(BMP280_ADDR_PRIMARY, 0xD0, &id, 1) && id == 0x58) {
    bmp280Addr_ = BMP280_ADDR_PRIMARY;
  } else if (i2cReadReg(BMP280_ADDR_SECONDARY, 0xD0, &id, 1) && id == 0x58) {
    bmp280Addr_ = BMP280_ADDR_SECONDARY;
  } else {
    return false;
  }
  if (!bmp280ReadCoefficients(bmp280Addr_)) {
    return false;
  }
  if (!i2cWriteByte(bmp280Addr_, 0xF4, 0x2F)) {
    return false;
  }
  return i2cWriteByte(bmp280Addr_, 0xF5, 0x90);
}

bool I2cSensorManager::bmp280Read(float *temperatureC, float *pressureHpa, float *altitudeM) {
  uint8_t d[6];
  if (!bmp280Present_ || !i2cReadReg(bmp280Addr_, 0xF7, d, sizeof(d))) {
    return false;
  }
  int32_t adcP = ((int32_t)d[0] << 12) | ((int32_t)d[1] << 4) | (d[2] >> 4);
  int32_t adcT = ((int32_t)d[3] << 12) | ((int32_t)d[4] << 4) | (d[5] >> 4);
  DEBUG_LOG("[sensor:bmp280:raw] addr=0x%02X bytes=%02X %02X %02X %02X %02X %02X adc_p=%ld adc_t=%ld\n",
            bmp280Addr_,
            d[0], d[1], d[2], d[3], d[4], d[5],
            static_cast<long>(adcP),
            static_cast<long>(adcT));

  int32_t var1 = ((((adcT >> 3) - ((int32_t)bmpDigT1_ << 1))) * ((int32_t)bmpDigT2_)) >> 11;
  int32_t var2 = (((((adcT >> 4) - ((int32_t)bmpDigT1_)) * ((adcT >> 4) - ((int32_t)bmpDigT1_))) >> 12) *
                  ((int32_t)bmpDigT3_)) >> 14;
  bmpTfine_ = var1 + var2;
  *temperatureC = ((bmpTfine_ * 5 + 128) >> 8) / 100.0f;

  int64_t pVar1 = ((int64_t)bmpTfine_) - 128000;
  int64_t pVar2 = pVar1 * pVar1 * (int64_t)bmpDigP6_;
  pVar2 = pVar2 + ((pVar1 * (int64_t)bmpDigP5_) << 17);
  pVar2 = pVar2 + (((int64_t)bmpDigP4_) << 35);
  pVar1 = ((pVar1 * pVar1 * (int64_t)bmpDigP3_) >> 8) + ((pVar1 * (int64_t)bmpDigP2_) << 12);
  pVar1 = (((((int64_t)1) << 47) + pVar1)) * ((int64_t)bmpDigP1_) >> 33;
  if (pVar1 == 0) {
    return false;
  }
  int64_t p = 1048576 - adcP;
  p = (((p << 31) - pVar2) * 3125) / pVar1;
  pVar1 = (((int64_t)bmpDigP9_) * (p >> 13) * (p >> 13)) >> 25;
  pVar2 = (((int64_t)bmpDigP8_) * p) >> 19;
  p = ((p + pVar1 + pVar2) >> 8) + (((int64_t)bmpDigP7_) << 4);
  *pressureHpa = (p / 256.0f) / 100.0f;
  *altitudeM = 44330.0f * (1.0f - powf(*pressureHpa / 1013.25f, 0.1903f));
  return true;
}

bool I2cSensorManager::as7341WaitBitClear(uint8_t reg, uint8_t bitMask, uint16_t timeoutMs) {
  uint32_t start = millis();
  uint8_t v = 0;
  do {
    if (!i2cReadReg(AS7341_ADDR, reg, &v, 1)) {
      return false;
    }
    if ((v & bitMask) == 0) {
      return true;
    }
    vTaskDelay(pdMS_TO_TICKS(2));
  } while (millis() - start < timeoutMs);
  return false;
}

bool I2cSensorManager::as7341WaitDataReady(uint16_t timeoutMs) {
  uint32_t start = millis();
  uint8_t v = 0;
  do {
    if (!i2cReadReg(AS7341_ADDR, 0xA3, &v, 1)) {
      return false;
    }
    if (v & 0x40) {
      return true;
    }
    vTaskDelay(pdMS_TO_TICKS(5));
  } while (millis() - start < timeoutMs);
  return false;
}

bool I2cSensorManager::as7341WriteSmux(const uint8_t *smux) {
  if (!i2cWriteByte(AS7341_ADDR, 0x80, 0x01)) {
    return false;
  }
  if (!i2cWriteByte(AS7341_ADDR, 0xAF, 0x10)) {
    return false;
  }
  for (uint8_t i = 0; i < 20; i++) {
    if (!i2cWriteByte(AS7341_ADDR, i, smux[i])) {
      return false;
    }
  }
  if (!i2cWriteByte(AS7341_ADDR, 0x80, 0x11)) {
    return false;
  }
  return as7341WaitBitClear(0x80, 0x10, 100);
}

bool I2cSensorManager::as7341Setup() {
  if (!i2cDevicePresent(AS7341_ADDR)) {
    return false;
  }
  return i2cWriteByte(AS7341_ADDR, 0x80, 0x01) &&
         i2cWriteByte(AS7341_ADDR, 0x81, 0x64) &&
         i2cWriteByte(AS7341_ADDR, 0xCA, 0xE7) &&
         i2cWriteByte(AS7341_ADDR, 0xCB, 0x03) &&
         i2cWriteByte(AS7341_ADDR, 0xAA, 0x09);
}

bool I2cSensorManager::as7341ReadSix(uint16_t *out) {
  if (!i2cWriteByte(AS7341_ADDR, 0x80, 0x03)) {
    return false;
  }
  if (!as7341WaitDataReady(400)) {
    i2cWriteByte(AS7341_ADDR, 0x80, 0x01);
    return false;
  }
  uint8_t d[12];
  if (!i2cReadReg(AS7341_ADDR, 0x95, d, sizeof(d))) {
    return false;
  }
  for (uint8_t i = 0; i < 6; i++) {
    out[i] = le16(d + i * 2);
  }
  i2cWriteByte(AS7341_ADDR, 0x80, 0x01);
  return true;
}

bool I2cSensorManager::as7341Read(uint16_t f[8], uint16_t *clear, uint16_t *nir) {
  static const uint8_t smuxLo[20] = {
      0x30, 0x01, 0x00, 0x00, 0x00, 0x42, 0x00, 0x00, 0x50, 0x00,
      0x00, 0x00, 0x20, 0x04, 0x00, 0x30, 0x01, 0x50, 0x00, 0x06};
  static const uint8_t smuxHi[20] = {
      0x00, 0x00, 0x00, 0x40, 0x02, 0x00, 0x10, 0x03, 0x50, 0x10,
      0x03, 0x00, 0x00, 0x00, 0x24, 0x00, 0x00, 0x50, 0x00, 0x06};
  uint16_t lo[6];
  uint16_t hi[6];
  if (!as7341WriteSmux(smuxLo) || !as7341ReadSix(lo)) {
    return false;
  }
  if (!as7341WriteSmux(smuxHi) || !as7341ReadSix(hi)) {
    return false;
  }
  DEBUG_LOG("[sensor:as7341:raw] lo=[%u,%u,%u,%u,%u,%u] hi=[%u,%u,%u,%u,%u,%u]\n",
            lo[0], lo[1], lo[2], lo[3], lo[4], lo[5],
            hi[0], hi[1], hi[2], hi[3], hi[4], hi[5]);
  f[0] = lo[0];
  f[1] = lo[1];
  f[2] = lo[2];
  f[3] = lo[3];
  f[4] = hi[0];
  f[5] = hi[1];
  f[6] = hi[2];
  f[7] = hi[3];
  *clear = (lo[4] + hi[4]) / 2;
  *nir = (lo[5] + hi[5]) / 2;
  return true;
}

bool I2cSensorManager::st25ReadUserMemory(char *buf, size_t len) {
  if (len == 0) {
    return false;
  }
  memset(buf, 0, len);
  Wire.beginTransmission(ST25_USER_ADDR);
  Wire.write(0x00);
  Wire.write(0x00);
  if (Wire.endTransmission(false) != 0) {
    return false;
  }
  size_t toRead = min(len - 1, static_cast<size_t>(220));
  size_t got = Wire.requestFrom(ST25_USER_ADDR, static_cast<uint8_t>(toRead));
  if (got != toRead) {
    DEBUG_LOG("[i2c:request-fail] sensor=st25 addr=0x%02X len=%u got=%u\n",
              ST25_USER_ADDR,
              static_cast<unsigned int>(toRead),
              static_cast<unsigned int>(got));
  }
  for (size_t i = 0; i < got && i < len - 1; i++) {
    char c = static_cast<char>(Wire.read());
    buf[i] = isPrintable(c) ? c : ' ';
  }
  buf[min(got, len - 1)] = 0;
  return got > 0;
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289

interface Env {
  DB: D1Database;
}

type JsonObject = Record<string, unknown>;

const DEVICE_ID_MAX_LENGTH = 128;
const DEVICE_ID_PATTERN = /^[A-Za-z0-9._:-]+$/;
const SENSOR_NAME_MAX_LENGTH = 128;
const SENSOR_NAME_PATTERN = /^[A-Za-z0-9._:-]+$/;

interface DeviceUploadPayload {
  deviceId: string;
  sensorData: Array<{
    name: string;
    data: string;
  }>;
  recordedAt: string;
}

export default {
  async fetch(request: Request, env: Env): Promise<Response> {
    try {
      const url = new URL(request.url);

      if (request.method === "OPTIONS") {
        return new Response(null, { status: 204, headers: corsHeaders() });
      }

      if ((url.pathname === "/health" || url.pathname === "/api/health") && request.method === "GET") {
        return jsonResponse({ ok: true });
      }

      if (url.pathname === "/device/upload" || url.pathname === "/api/device/upload") {
        if (request.method !== "POST") {
          return jsonError("method_not_allowed", "Use POST /api/device/upload.", 405);
        }

        return handleDeviceUpload(request, env);
      }

      return jsonError("not_found", "Route not found.", 404);
    } catch (error) {
      console.error("Unhandled request error", error);
      return jsonError("internal_error", "Internal server error.", 500);
    }
  }
} satisfies ExportedHandler<Env>;

async function handleDeviceUpload(request: Request, env: Env): Promise<Response> {
  const contentType = request.headers.get("content-type") ?? "";
  if (!contentType.toLowerCase().includes("application/json")) {
    return jsonError("unsupported_media_type", "Request body must be JSON.", 415);
  }

  const payload = await parseJsonObject(request);
  if (!payload.ok) {
    return jsonError("invalid_json", payload.error, 400);
  }

  const upload = normalizeDeviceUploadPayload(payload.value);
  if (!upload.ok) {
    return jsonError(upload.code, upload.error, 400);
  }

  console.log(
    JSON.stringify({
      event: "device_upload_received",
      device_id: upload.value.deviceId,
      time: upload.value.recordedAt,
      sensor_count: upload.value.sensorData.length,
      sensor_names: upload.value.sensorData.map((sensor) => sensor.name)
    })
  );

  const receivedAt = new Date().toISOString();

  const statements = [
    env.DB.prepare(
      `INSERT INTO device (device_id, first_seen_time, last_upload_time, upload_count)
       VALUES (?1, ?2, ?2, 1)
       ON CONFLICT(device_id) DO UPDATE SET
         last_upload_time = excluded.last_upload_time,
         upload_count = device.upload_count + 1`
    ).bind(upload.value.deviceId, receivedAt),
  ];
  const dataIds: string[] = [];

  for (const sensor of upload.value.sensorData) {
    const dataId = crypto.randomUUID();
    dataIds.push(dataId);

    statements.push(
      env.DB.prepare(
        `INSERT INTO sensor_data
           (data_id, device_id, sensor_name, data, time, upload_time)
         VALUES (?1, ?2, ?3, ?4, ?5, ?6)`
      ).bind(
        dataId,
        upload.value.deviceId,
        sensor.name,
        sensor.data,
        upload.value.recordedAt,
        receivedAt
      )
    );
  }

  await env.DB.batch(statements);

  console.log(
    JSON.stringify({
      event: "device_upload_stored",
      device_id: upload.value.deviceId,
      time: upload.value.recordedAt,
      upload_time: receivedAt,
      sensor_count: upload.value.sensorData.length,
      data_ids: dataIds
    })
  );

  return jsonResponse(
    {
      ok: true,
      device_id: upload.value.deviceId,
      time: upload.value.recordedAt,
      upload_time: receivedAt,
      sensor_count: upload.value.sensorData.length,
      data_ids: dataIds
    },
    201
  );
}

async function parseJsonObject(
  request: Request
): Promise<{ ok: true; value: JsonObject } | { ok: false; error: string }> {
  try {
    const value: unknown = await request.json();
    if (!isJsonObject(value)) {
      return { ok: false, error: "JSON body must be an object." };
    }

    return { ok: true, value };
  } catch {
    return { ok: false, error: "Malformed JSON body." };
  }
}

function normalizeDeviceUploadPayload(
  payload: JsonObject
): { ok: true; value: DeviceUploadPayload } | { ok: false; code: string; error: string } {
  const deviceId = normalizeDeviceId(payload.device_id);
  if (!deviceId.ok) {
    return { ok: false, code: "invalid_device_id", error: deviceId.error };
  }

  const recordedAt = normalizePayloadTime(payload.time);
  if (!recordedAt.ok) {
    return { ok: false, code: "invalid_time", error: recordedAt.error };
  }

  if (!isJsonObject(payload.sensor_data)) {
    return { ok: false, code: "invalid_sensor_data", error: "sensor_data must be a non-empty JSON object." };
  }

  const sensors = Object.entries(payload.sensor_data);
  if (sensors.length === 0) {
    return { ok: false, code: "invalid_sensor_data", error: "sensor_data must contain at least one sensor." };
  }

  const sensorData = [];
  for (const [name, value] of sensors) {
    const sensorName = normalizeSensorName(name);
    if (!sensorName.ok) {
      return { ok: false, code: "invalid_sensor_name", error: sensorName.error };
    }

    if (value === undefined) {
      return { ok: false, code: "invalid_sensor_value", error: `Sensor ${name} has an unsupported value.` };
    }

    sensorData.push(normalizeSensorReading(sensorName.value, value));
  }

  return {
    ok: true,
    value: {
      deviceId: deviceId.value,
      sensorData,
      recordedAt: recordedAt.value
    }
  };
}

function normalizeDeviceId(rawValue: unknown): { ok: true; value: string } | { ok: false; error: string } {
  if (typeof rawValue !== "string" || rawValue.trim() === "") {
    return { ok: false, error: "device_id is required and must be a non-empty string." };
  }

  const value = rawValue.trim();
  if (value.length > DEVICE_ID_MAX_LENGTH) {
    return { ok: false, error: `Device id must be ${DEVICE_ID_MAX_LENGTH} characters or fewer.` };
  }

  if (!DEVICE_ID_PATTERN.test(value)) {
    return { ok: false, error: "Device id may contain only letters, numbers, dot, underscore, colon, and dash." };
  }

  return { ok: true, value };
}

function normalizeSensorName(value: string): { ok: true; value: string } | { ok: false; error: string } {
  const normalized = value.trim();
  if (normalized === "") {
    return { ok: false, error: "Sensor name must not be empty." };
  }

  if (normalized.length > SENSOR_NAME_MAX_LENGTH) {
    return { ok: false, error: `Sensor name must be ${SENSOR_NAME_MAX_LENGTH} characters or fewer.` };
  }

  if (!SENSOR_NAME_PATTERN.test(normalized)) {
    return { ok: false, error: "Sensor name may contain only letters, numbers, dot, underscore, colon, and dash." };
  }

  return { ok: true, value: normalized };
}

function normalizePayloadTime(value: unknown): { ok: true; value: string } | { ok: false; error: string } {
  if (typeof value === "string") {
    const date = new Date(value);
    if (!Number.isNaN(date.getTime())) {
      return { ok: true, value: date.toISOString() };
    }
  }

  if (typeof value === "number" && Number.isFinite(value)) {
    const milliseconds = value < 10_000_000_000 ? value * 1000 : value;
    const date = new Date(milliseconds);
    if (!Number.isNaN(date.getTime())) {
      return { ok: true, value: date.toISOString() };
    }
  }

  return { ok: false, error: "time must be an ISO timestamp string, Unix seconds, or Unix milliseconds." };
}

function normalizeSensorReading(name: string, value: unknown): DeviceUploadPayload["sensorData"][number] {
  return {
    name,
    data: JSON.stringify(value)
  };
}

function isJsonObject(value: unknown): value is JsonObject {
  return typeof value === "object" && value !== null && !Array.isArray(value);
}

function jsonResponse(body: JsonObject, status = 200): Response {
  return new Response(JSON.stringify(body), {
    status,
    headers: {
      "content-type": "application/json; charset=utf-8",
      ...corsHeaders()
    }
  });
}

function jsonError(code: string, message: string, status: number): Response {
  return jsonResponse(
    {
      ok: false,
      error: {
        code,
        message
      }
    },
    status
  );
}

function corsHeaders(): HeadersInit {
  return {
    "access-control-allow-origin": "*",
    "access-control-allow-methods": "GET,POST,OPTIONS",
    "access-control-allow-headers": "content-type,x-device-id"
  };
}
